The Rain Bird 100-DV is a proven 1-inch solenoid valve widely used in residential and commercial irrigation. Unlike the 100-DVF, this model does not include integrated flow control, making it a streamlined and cost-effective option. It features 1" BSP female threaded connections, robust PVC body with stainless steel screws. The dual filtration system protects against debris. An external manual bleed allows maintenance flushing. With a flow range of 0.24 to 9.0 m3/h and working pressure of 1 to 10.4 bar. Compatible with all standard 24 VAC controllers.
Technical specifications
- Model: 100-DV
- Connection: 1" BSP Female
- Voltage: 24 VAC
- Flow: 0.24-9.0 m3/h
- Pressure: 1-10.4 bar
- Body: PVC
- Filtration: Dual
- Flow Control: No
- Manual Bleed: External
