Rain Bird Falcon 6504 PC Rotor Sprinkler

The Rain Bird Falcon 6504 is a heavy-duty long-range rotor for parks, sports fields and large lawns, here in the plastic riser version. Its water-lubricated gear drive turns reliably, and the arc can be set from 40° to 360° with a flat-blade screwdriver, with or without the rotor running. It reaches an 11.9–19.8 m radius at 2.1–6.2 bar with a flow of 0.66–4.93 m³/h, and its removable check device handles elevation changes of up to 3.1 m. A dependable choice for parks and large lawns. Its 1" inlet and heavy-duty construction make it a good fit for large public and commercial landscapes where long throw distances reduce the number of heads needed.

Technical specifications

• Brand: Rain Bird
• Model: Falcon 6504 PC
• Arc: 40-360°
• Radius: 11.9–19.8 m
• Operating pressure: 2.1–6.2 bar
• Flow: 0.66–4.93 m³/h
• Pop-up height: 10.2 cm (4 in)
• Inlet: 1" female (NPT/BSP)
• Riser: Plastic
• Included: 1 rotor sprinkler, plastic riser
• Type: Long-range pop-up rotor sprinkler
